Beskrivning
Art.nr: TRS-0700P-2
Total power
700 W
AC input voltage
230 V
AC input frequency
50 - 60 Hz
Input current
9 A
Power Factor Correction (PFC) type
Active
Combined power (+3.3V)
120 W
Combined power (+12V)
648 W
Combined power (+5V)
120 W
Combined power (-12V)
6 W
Combined power (+5Vsb)
12.5 W
Max output current (+3.3V)
24 A
Max output current (+12V)
54 A
Max output current (+5V)
17 A
Max output current (-12V)
0.5 A
Max output current (+5Vsb)
2.5 A
Hold time
16 ms
Efficiency
86 %
Fan diameter
120 mm
Number of fans
1 fan(s)
Fan location
Top
Fan speed
1800 RPM
Cooling type
Active
Motherboard power connector
20+4 pin ATX
Peripheral (Molex) power connectors (4-pin)
5
Number of SATA power connectors
6
PCI Express power connectors (6+2 pin)
2
CPU power connector (4+4 pin)
Yes
ATX power connector (20+4 pin)
Yes
Floppy disk drive connector
Yes
Purpose
PC
Power supply unit (PSU) form factor
ATX
ATX version
2.3
Mean time between failures (MTBF)
100000 h
Colour of product
Black
Operating temperature range (T-T)
5 - 40 °C
Storage temperature (T-T)
-40 - 55 °C
Operating relative humidity range
20 - 85 %
Storage relative humidity (H-H)
10 - 95 %
Width
150 mm
Depth
140 mm
Height
86 mm
80 PLUS certification
80 PLUS
Certification
CE/CB/TUV
Packaging type
Box
